Samsung 86" WAD Series Interactive E-Board

A Classroom Display Built to Run All Day, Every Day

Designed for schools and offices that need a display running well beyond a typical workday, this 86" panel is rated for 12/7 continuous operation. A 4K UHD IPS panel with 400-nit brightness and 178°/178° viewing angles keeps lessons and presentations readable from anywhere in the room, while infrared touch supports up to 40 points with dual-pen functionality for side-by-side handwriting.

Android 13 runs built-in apps directly from 64GB of onboard storage, so lessons and presentations can start without a connected PC. A 3-in-1 USB-C port handles touch control, screen mirroring, and charging up to 65W, making it simple to connect and power a laptop with a single cable.

Connectivity covers three HDMI inputs, five USB ports, RS232 and RJ45 for room control systems, plus built-in Wi-Fi and Bluetooth. A VESA 800x600mm mount supports standard classroom and office wall installations.

Key Features

• 12/7 Continuous Operation: Built for all-day classroom and office use.
• 40-Point IR Touch with Dual Pen: Supports simultaneous side-by-side writing.
• Android 13 Built-In: Run apps and lessons directly, no PC required.
• 3-in-1 USB-C: Touch control, screen mirroring, and 65W charging over one cable.
• 4K UHD IPS Panel: Sharp, wide-angle visibility for any seat in the room.

Specifications

• Display: 86" IPS, 3840x2160 (4K UHD), 178°/178° viewing angle
• Brightness/Contrast: 400 nits, 1200:1
• Response Time: 8ms
• Touch: IR, up to 40 points, dual pen support
• OS: Android 13, 64GB storage
• Ports: HDMI in x3 (v2.0, HDCP 2.1), USB 2.0 x1, USB 3.0 x4, USB-C (touch/mirroring/65W charging), RS232 in/out, RJ45 in/out, IR in, stereo audio in/out, video out
• Connectivity: Wi-Fi, Bluetooth
• Operation: 12/7 continuous use rated
• VESA Mount: 800x600mm
• Power: 486W on mode, ≤0.5W sleep mode
• Dimensions: 1957 x 1160 x 99mm
• Weight: 56.5kg
